PRESTO CHEF – PROFESSIONNAL KITCHEN RANGE – « Mini » Column –deck-mounted mixer -rinsing head / 70830

THE PRODUCT BENEFITS
“Mini” format particularly suitable for small spaces: space saving
Resistant to intensive use
Spring flexibility
Ergonomic hand shower with continuous flow function, and gripping surface limiting the risk of burns
Fast filling of tanks: 26L / min at 3 bar
Reinforced body / column interface
Intuitive and ergonomic knobs: easy grip
Product design
Locking hook to avoid MSD (musculoskeletal disorder)
PU sheath shower hose to avoid bacterial niches and facilitate cleaning
Easy maintenance: presence of a slot under the red / blue pad allowing the passage of a screwdriver
Ease of maintenance: availability of all spare parts
Flow straightener to channel water and avoid lateral water splashes
Dimensions:
Overall height: 764 mm
Model:
Single-turn mixer with ceramic head 1/4 turn with flow rate of 26L / min at 3 bar
1/4 turn ceramic head tap with filling spout 250 mm projection – adjustable
Black hand shower M 1/2 ” with grip surface limiting the risk of burns
Shower flow: 12L / Min (regulated) – User adjustable jet: concentrated or wetting – Anti-tartar spray nozzle – Locking hook for continuous flow – integrated NF check valve
Interchangeable anti-tartar flow straightener
Guide spring for stainless steel hose
Adjustable shower holder on the left or right
Recommended working pressure:
1 to 5 bars
 Flow rate:
26L / min at 3 bar
Hydraulic supply:
G 1/2 ” (15x 21)
 Material and color of finish:
Body, spout and column in chromed brass
Injected metal hook
Material compliant with the “UBA” list
 Thermal resistance :
Withstands a temperature of 75 ° C for 30 minutes (in the context of thermal shock).
Delivered with :
1 fixing bracket
2 PEX flexible hoses with stainless steel braided nut G1 / 2 ” Lg 660 mm with non-return valves NF
1 filter
1 stainless steel braided hose (hand shower) Lg 1 m surrounded by a PVC sheath, resistant to temperatures up to 90 ° C. Continuous operating temperature at 70 ° C maximum
